P/H Series Self-Centering Vises
Features:
Automation Vises
· Specially designed for automation
· A variety of available jaws
· Positioning repeatability to 0.01mm
· Fully sealed to keep liquid, chips and dirt away
· Designed to prevent jaws from moving up
· Pneumatic or hydraulic driven
· Power feed by side or from the bottom
· All parts hardened and ground
· Ideal for 5-axis machining
Please choose the model, then ask for quotation or add to cart.
Technical Parameter
Stroke: 5mm
Order Code | Description |
YP080150 | Pneumatic vise Include a pair of PJ08001 jaws |
YH080150 | Hydraulic vise Include a pair of PJ08001 jaws |
*Connect couplings are not included.”
